● ● Rated voltage: AC100V~240V±10%, 50-60Hz
● ● Rated power: 500W
● ● Light source: 300W LED module
● ● Color temperature: 7300K
● ● Lamp life: 1500 hours
● ● Control modes: DMX, auto-propelled, master-slave, voice control
● ● DMX channels: 22/26 international standard DMX channels
● ● Signal input: Standard three-pin/five-pin signal socket input and output
● ● 3-in-1 optical lens design: (BEAM mode): 2°; (SPOT pattern mode): 4°~52°; (WASH pattern mode): 2°~46°. Three modes can be switched to achieve beam, wash, and pattern functions.
● ● Strobe: Strobe speed 0.5-25 Hz
● ● Color Wheel: 1 color wheel with 6 colors + white light + linear CTO, with half-color and bidirectional flow options, color transitions, and a half-color rainbow effect.
● ● Fixed Gobo Wheel: 1 fixed gobo wheel with 9 gobos + white light, each with a dithering effect, and a forward/reverse fast/slow flowing effect.
● ● Rotating Gobo Wheel: 1 rotating gobo wheel with 7 optional gobos + white light, each with forward/reverse rotation and a dithering effect, and a forward/reverse fast/slow flowing effect.
● ● Linear CMY function. Infinite color mixing.
● ● Prism Focus: The prism allows for linear zooming in and out, with adjustable clarity.
● ● Focusing: Utilizing high-precision glass optical lenses and electronic focus design, ultra-smooth focus adjustment is achieved. ● ● Atomization: 0% to 100% uniform soft light atomization effect
● ● Horizontal Scanning: X-axis: 540°, 16-bit
● ● Vertical Scanning: Y-axis: 270°, 16-bit
● ● Signal Protection: Built-in input signal isolation protection ensures stable signal transmission.
● ● Display: LCD display, touch screen + button control, more user-friendly and convenient operation, built-in Chinese and English display interface switching, and intelligent 180-degree flip and inversion.
● ● Intelligent Fan Speed Control: Built-in intelligent fan speed control function automatically reduces power when the lamp is at high temperature, and the entire fan operates at low speed. This can effectively meet the actual needs of the performance venue, reduce fan noise output, and create a good performance atmosphere.
● ● Operation Page: Built-in multiple pages with sub-item design functions. Function modes can be customized according to the usage scenario, and built-in password lock protection is included. ● ● Lamp Fault Display: Intelligent microcomputer self-diagnosis displays self-diagnosis information on the display, allowing for quick fault diagnosis and repair.
● ● Intelligent Control: Built-in RDM and autofocus functions automatically modify address codes via signal lines, detect lamp faults, and update program versions for intelligent control.
● ● Automatic Error Correction: Horizontal and vertical positions utilize a photoelectric reset system, automatically resetting the lamp in the event of an accidental error.
● ● Exterior Material: Injection molded from high-temperature, flame-resistant engineering plastic.
● ● Protection Rating: IP20
● ● Operating Temperature: -20°C to 40°C
● ● Product Dimensions: 578mm (H) x 325mm (W) x 249mm (D)
● ● Packaging Weight: 17.5kg
